X-Series Video Servers


Wavestore X-Series video servers deliver an enterprise recording, management and control solution for large size projects that demand mission-critical reliability. Up to 254 network cameras can be connected to each video server, which are supplied with pre-installed Wavestore’s Video Management Software (VMS). Throughput options up to 2,400Mbits/sec are available, with multiple network interfaces to segregate incoming and outgoing network traffic. Ports can be bonded to provide fault-tolerance and maintain high-performance at all times.

Housed in a rack mountable 4U case, X-Series video servers come complete with dual power supply as standard and can accommodate up to 24 x 3.5” hot swappable hard drives to provide up to 336TB of storage. This can deliver more than 48 days continuous real-time recording from 254 Full HD cameras with RAID5 redundancy.

At a glance

Form factor: 4U rackmount

IP video channels: Up to 254

Max. HDDs: 24 x hot swap

Max. storage: 336TB

Max. IP throughput: Options up to 2,400Mbits/sec

RAID: HyperRAID™ ready (up to N+5)

HDD spin down: EcoStore™ ready

Failover ready: Yes

Operating System (OS): Linux with VMS embedded

Wavestore VMS: Pre-installed, ready to licence any level

Quick Camera Group setup: Yes

On-board WaveView client operation: For set-up only

Remote WaveView & WaveView Mobile client operation: Yes

Dual PSU: Yes

Standard warranty: Three-Years

Extended warranty: Five-years (optional)

Key features

Pre-installed with Wavestore’s highly secure VMS embedded into its Linux Operating System (OS)

Compatible with all Wavestore VMS levels
Up to 4096bit encryption with comprehensive cyber-security package provided as standard
EcoStore™ ready*
HyperRAID ready*
Fully ONVIF conformant and truly open-platform


Wavestore X-Series Datasheet
